ETLETL NA ProductSelected for North America lighting projects and compliance-focused sourcing.
Commercial recessed downlight series for higher-output ceiling lighting in offices, retail, hospitality and public spaces.
Key Specifications
- Size: 4 inch / 6 inch / 8 inch class options
- Voltage: AC100-277V
- Power: selectable wattage options
- CCT: commercial CCT options
- Beam: wide general lighting distribution
- Installation: recessed commercial downlight
Main Features
- Commercial-grade recessed downlight construction
- High lumen output for large spaces
- Selectable wattage options on selected models
- Suitable for new construction and renovation projects
- Clean trim design for professional interiors
Applications
Recommended for North American residential, hospitality, retail, commercial and outdoor lighting projects depending on installation environment.
Specification
| Model | LED Type | Voltage | Wattage | Lumens | CCT | Cutout Size | Dimension |
|---|---|---|---|---|---|---|---|
| YBL-COB04-F15W-41 | COB | AC 100–277V | 9W / 12W / 15W | 1200 lm | 5CCT Tunable | Ø108 mm | Ø130 × 72.5 mm |
| YBL-SMD04-E15W-41 | SMD | AC 100–277V | 9W / 12W / 15W | 1200 lm | 5CCT Tunable | Ø108 mm | Ø130 × 72.5 mm |
| YBL-COB06-F28W-41 | COB | AC 100–277V | 18W / 23W / 28W | 2000 lm | 5CCT Tunable | Ø165 mm | Ø191 × 110 mm |
| YBL-SMD06-E28W-41 | SMD | AC 100–277V | 18W / 23W / 28W | 2000 lm | 5CCT Tunable | Ø165 mm | Ø191 × 110 mm |
| YBL-COB08-F38W-41 | COB | AC 100–277V | 28W / 33W / 38W | 2800 lm | 5CCT Tunable | Ø195 mm | Ø227 × 110 mm |
| YBL-SMD08-E38W-41 | SMD | AC 100–277V | 28W / 33W / 38W | 2800 lm | 5CCT Tunable | Ø195 mm | Ø227 × 110 mm |
