PRODUCT CODE: YBL-GL-480W / YBL-GL-640W / YBL-GL-1000W
Full Spectrum LED Grow Light — Commercial Grade
Samsung LM301H EVO chips · Osram 660nm red · Precise spectrum for every growth stage. Designed for vertical farms, greenhouses and indoor cultivation.
Full Spectrum Coverage (380nm – 780nm)
Select Model
Spectrum Configuration
Proven across cannabis, herbs & vegetables
Custom spectrum & private label
50+ countries, DDP available
Commercial Grow Lighting Built for Maximum Yield
The YBL-GL Series is engineered for professional cultivators who demand consistent, high-PPFD light output with the energy efficiency to keep operating costs competitive. Powered by Samsung LM301H EVO chips — the gold standard in horticulture — paired with Osram 660nm deep red for optimal photosynthesis activation.
Whether you're running a large-scale vertical farm, a greenhouse operation or a multi-tier cannabis facility, the YBL-GL delivers the light your plants need at every growth stage.
- Samsung LM301H EVO LEDs — highest efficacy commercial grow chips available
- Osram 660nm deep red diodes for flowering stage boost
- Up to 3.0 μmol/J PPE — industry-leading energy efficiency
- 0–100% dimming via RJ14 daisy-chain or 0–10V signal
- Fanless passive cooling — zero noise, zero maintenance
- Universal voltage AC 100–277V for global deployment
- IP65 driver — humidity resistant for greenhouse environments
- 5-year warranty — backed by YouBeeLight quality guarantee
Samsung LM301H EVO Chips
The latest generation of Samsung horticultural LEDs — delivering superior photon output per watt with exceptional longevity over 100,000+ hours.
Passive Heatsink Cooling
Fanless aluminum heatsink design eliminates moving parts, reduces noise to 0dB and ensures reliable operation in humid grow environments.
Smart Dimming Control
RJ14 daisy-chain up to 100 fixtures per controller. Compatible with most commercial grow controllers including Priva, Argus and custom BMS systems.
Uniform PPFD Distribution
Precision optical design achieves ≤15% PPFD uniformity variance across the coverage footprint — eliminating hot spots and maximizing canopy efficiency.
Universal Voltage
AC 100–277V wide-range input supports single and three-phase installations worldwide without voltage conversion hardware.
Private Label OEM
Full OEM service including custom spectrum ratios, housing color, branding and packaging. MOQ 50 pcs for standard models, 200+ for custom spectrum.
Precision Full Spectrum — Optimized for All Growth Stages
The YBL-GL spectrum is engineered to match the absorption peaks of chlorophyll A, chlorophyll B and phytochromes — maximizing photosynthetic efficiency across the entire plant lifecycle.
Blue (400–500nm)
~20% ratio
Vegetative growth, compact structure, stomata regulation
Green (500–600nm)
~10% ratio
Canopy penetration, lower leaf photosynthesis
Red (600–700nm)
~65% ratio
Peak photosynthesis, flowering trigger, yield maximization
Far-Red + IR (700–780nm)
~5% ratio
Emerson effect, stem elongation, ripening acceleration
Custom Spectrum Available
For OEM partners requiring specific spectral configurations — seedling, vegetative, flowering or fruiting optimized spectrums — YouBeeLight offers full custom spectrum design with photometric testing report. Minimum order 200 pcs. Contact us with your target crops and growth parameters.
| Parameter | Specification |
|---|---|
| Product Identification | |
| Model Number | YBL-GL-480W / YBL-GL-640W / YBL-GL-1000W |
| Series | YBL-GL (Grow Light Series) |
| Brand | YouBeeLight |
| Optical & Photometric | |
| Actual Power Draw | 480W ±5% / 640W ±5% / 1000W ±5% |
| PPE Efficacy | 2.7 μmol/J (480W) / 2.9 μmol/J (640W) / 3.0 μmol/J (1000W) |
| Total PPF Output | 1,296 μmol/s / 1,856 μmol/s / 3,000 μmol/s |
| Peak PPFD (12" height) | 1,800+ / 2,200+ / 3,500+ μmol/m²/s |
| Recommended Hanging Height | Veg: 24–36" / Flower: 18–24" |
| Coverage Area (Flower) | 4×4 ft / 5×5 ft / 6×6 ft |
| Coverage Area (Veg) | 5×5 ft / 6×6 ft / 8×8 ft |
| Spectrum | Full Spectrum 380–780nm (UV + Blue + Green + Red + Far-Red + IR) |
| Red:Blue Ratio | ~3.2:1 (customizable for OEM) |
| R:FR Ratio | ~8:1 |
| LED Components | |
| Main Chips | Samsung LM301H EVO (3000K + 5000K blend) |
| Red Chips | Osram SSL660 (660nm deep red) |
| Far-Red Chips | Epistar 730nm far-red (optional) |
| LED Count | 1,680 pcs (480W) / 2,240 pcs (640W) / 3,584 pcs (1000W) |
| LED Lifespan | >100,000 hours (L90) |
| Electrical | |
| Input Voltage | AC 100–277V, 50/60Hz (Universal) |
| Power Factor | >0.95 |
| THD | <10% |
| Dimming | 0–100% via RJ14 daisy-chain or 0–10V analog signal |
| Surge Protection | 4kV line-to-line |
| Driver Brand | Inventronics / Meanwell (custom available) |
| Driver IP Rating | IP65 — humidity resistant |
| Physical | |
| Dimensions (480W) | 1,140 × 1,140 × 90mm |
| Dimensions (640W) | 1,280 × 1,280 × 90mm |
| Dimensions (1000W) | 1,560 × 1,560 × 90mm |
| Net Weight | 12.5 kg / 16.8 kg / 24.0 kg |
| Housing Material | Aluminum alloy — anodized black |
| Cooling Method | Passive heatsink — fanless, 0dB |
| Hanging System | Adjustable steel cable with ratchet (included) |
| IP Rating | IP65 (driver) / IP42 (fixture) |
| Environmental & Reliability | |
| Operating Temperature | -20°C to +40°C |
| Humidity | 0–90% RH (non-condensing) |
| Fixture Lifespan | >50,000 hours system lifespan |
| Warranty | 5 Years |
| Certifications | CE, RoHS, FCC, CB, UL (optional) |
| MOQ | 10 pcs (standard) / 50 pcs (OEM) |
Note: PPF, PPFD and PPE values measured at standard test conditions. Custom wattage (200W–2000W), spectrum configurations and certifications available for OEM orders. Contact us for a custom datasheet and photometric IES file.
The YBL-GL Series is trusted by professional cultivators across a wide range of high-value crop applications.
Cannabis Cultivation
Optimized red/blue ratio for both vegetative and flowering stages — maximizes trichome density and yield
Leafy Greens & Herbs
Ideal for lettuce, spinach, basil, mint and other high-turnover crops in vertical farms
Fruiting Vegetables
High-intensity full spectrum drives consistent flowering and fruit set in tomatoes, peppers and cucumbers
Floriculture
Far-red supplementation accelerates flowering and controls photoperiod in roses, chrysanthemums and orchids
Vertical Farming
Low-profile design and daisy-chain dimming ideal for multi-tier vertical cultivation systems
Propagation & Cloning
Dimming capability at 10–30% power for seedling and clone stages without light stress
Greenhouse Supplemental
UV-stable housing suitable for greenhouse HPS replacement or inter-lighting supplemental applications
Research & Phenotyping
Custom spectrum configurations available for plant science research institutions and phenotyping facilities
YBL-GL products are certified for global market distribution. All certificates available for download upon request.
CE Marking
Compliant with EU LVD and EMC directives. Required for all European market sales and distribution.
RoHS Compliant
All materials are free from restricted hazardous substances per EU RoHS 2 directive.
FCC (USA)
FCC Part 15 compliant — approved for sale and distribution across the United States.
CB Scheme
CB test report accepted in 50+ countries — significantly reduces certification costs for multi-market OEM buyers.
UL Listing (Optional)
UL 8800 horticulture lighting listing available for US commercial facility compliance requirements.
Custom Certifications
UKCA (UK), SAA (Australia), EAC (Russia/CIS) and other regional certifications available for OEM orders 500+ pcs.
Ready to Source the YBL-GL Series?
Tell us your cultivation setup, target crop and required wattage. We'll respond with pricing, PPFD maps and availability within 24 hours.
